    6 reasons why your video management system needs a drone

    May 22, 2019
    Expanded surveillance, alarm and forensic capabilities push user case for technology
    Over the last few decades, and more rapidly in the last few years, advancements in lighter and more powerful batteries and smaller camera technology has allowed for lighter payloads, which equates to lower cost and longer operating cycles.
    Over the last few decades, and more rapidly in the last few years, advancements in lighter and more powerful batteries and smaller camera technology has allowed for lighter payloads, which equates to lower cost and longer operating cycles.

    Surveillance drones are here and ready to be deployed as an additional sensor in your video management system.

    What was once just science fiction, along with artificial intelligence and driverless cars, surveillance drones are now very real and an affordable and effective video surveillance option.  Here are the top reasons you should consider integrating a drone into your video management system.

    1) Technology Advancements

    So why are we suddenly talking about drones? They’ve been around for quite some time, in fact military records go back to World War I in 1916. Mini and Micro versions have been around since the early 90’s. So, what’s changed? Mainly capability and affordability. Over the last few decades, and more rapidly in the last few years, advancements in lighter and more powerful batteries and smaller camera technology has allowed for lighter payloads, which equates to lower cost and longer operating cycles. Likewise, improvements in wireless video and gimbal technology removes vibration and flight effects of the drone, allowing for high quality, streaming video from the drone to the VMS for continuous surveillance. When properly integrated with your VMS system, the consideration to use a drone is almost similar to adding a new PTZ camera to obtain longer range.

    2) Dispatch to Alarms

    One of the most obvious and likely the highest value proposition of integrating a drone into your VMS system is the Dispatch to Alarm capability. Most of today’s high-performance VMS systems are geospatial, or map-based. (If your VMS is not geospatial, shame on you, it’s time to give up the Motorola Startac flip phone and get an iPhone X). Geospatial video management systems understand the physical location of security detection points (gates, doors, windows), as well as, real-time locations of detected intrusions from video cameras, radars, fence or proximity sensors.  This allows it to easily dispatch a drone to an exact location using the geographical coordinate of the event. Without any user interaction, the system can turn on the drone, initiate take off, load the destination information and even provide waypoints to guide the flight path. The drone can arrive in a fraction of the time of a traditional response action to provide additional video of the event.

    3) Flexible Surveillance Options

    A drone can allow you to place a camera almost anywhere. This opens many surveillance options. You may have a region that is too rugged to allow cost effective sensor placement, a drone can help monitor these regions. They can also respond to non-video sensor alarms, such as radar, GPS, fence systems or even remote access control. If visual confirmation is required, but there is no PTZ in the area with line of sight to the alarm, a drone can help service this request.

    It can also serve as a video source for short term missions, or special events, such as visiting dignitaries, company events or even construction actions which may create temporary breaches in the perimeter. Drones can augment existing measures, or act as additional surveillance to avoid installation of short-term monitoring equipment.

    4) Airborne Intelligence and Tracking

    Just as fixed cameras and PTZ cameras can be armed with intelligence via video analytics, on-board drone cameras can benefit from these same algorithms. As such, drones have the ability to detect intrusions, classify target, count objects and alarm based on detection zones.  This capability is available in both hover modes and while in flight. Advanced gimbals, intelligent camera control and software stabilized video provides high quality scenes for operator viewing and intelligent video analysis.

    In addition to detection capability, PTZ follow algorithms may also be deployed on drone cameras. Much like a fixed location PTZ, PTZ follow or camera follow, allows the software to control the pan, tilt and zoom of a camera to keep a target centered in the cameras field of view as the target continues in motion. When deployed on a drone camera, this ability to keep the target centered in the camera’s view remains true, as both the target and drone move independently.

    5) After Breach Continuous Coverage

    Deployment of PTZ follow algorithms on drone-based cameras allow for another significant capability; the ability to continue to follow the intruder after the breach. Keeping eyes on the target is critical, but even with a robust PTZ camera design, costs and viewshed issues can cause potential blind spots once the perimeter has been breached. In these cases, a drone can be deployed to provide coverage in these areas. Today’s micro and mini sized drones are capable of carrying a camera payload, meaning there are few locations which would not be accessible.

    6) Expanded Patrol Options

    A drone can be a valuable addition to your patrol operations, even without the need to have a person trained to fly it. Today’s drones can include pre-programmed flight plans, where specific events or scheduled timings can allow the drone to automatically take off and fly its route, actively monitoring for and detecting intrusions along its route.

    Likewise, an operator can provide a custom flight path, through interaction with the map-based VMS user interface. In all cases, when flying in an autopilot mode, video algorithms combined with property elevation models and other sensors allow the drone to maneuver around obstacles and then return to its flight path.

    These patrol options can be very beneficial in cases where you have limited manpower for consistent patrols, or if patrols require entrance into rough terrain, or potentially hazardous regions of a facility.

    The value proposition from adding a drone comes from proper integration with your video management system.

    So How Do I Add a Drone to My VMS?

    Adding a drone to your surveillance solution can be as easy as placing an order on Amazon and getting your 2-day free shipping, however, much of the value proposition comes from proper integration with your VMS system. The includes be able to receive the live drone video directly into your VMS, automatic dispatch to an alarm location, display and tracking of the drone location, as well as, the ability to issue basic drone commands directly from the VMS (Track Target, Begin Patrol, Return to Base, Land, etc.).

    The Fine Print

    When it comes to drones, there is fine print. Drones hang out in airspace, which in the United States, is the domain of the FAA. As such, drones are subject to the jurisdiction of this agency.  There are still some gotchas when it comes to operational allowances, granting of waivers and line of sight issues. However, as more drones enter the sky, guidelines and rules are being modified to accommodate. The good news is, if cars without drivers can motor around our roadways with little to no oversight, then the future looks good for the autonomous use of drones for security on your property.

    Want to learn more about geospatial video management systems?  Check out our videos and product capabilities.

    About the author: Eric Olson is Vice President of Marketing at Phoenix-based video analytics developer PureTech Systems (www.puretechsystems.com). He can be contacted at [email protected] or connect at www.linkedin.com/in/ericolsonaz.
